High Pressure Hoses Range

Hydraulic hoses are made in different materials depending on the usage, climate conditions, pressure, and operating environment.

These high-pressure hoses are made to exceed ISO 8752 specifications and consistently outperform conventional multi-spiral hoses to serve the needs of our customers.

At BOA Hydraulics, our high-pressure hydraulic hoses are durable, of high-quality, with a good service life.

Our High Pressure Hydraulic Hose

1. 1SN/ R1AT 1-Wire Hydraulic Hose

• Application: For low and medium high pressure circuits, return hoses.
• Inner Layer: Oil resistant synthetic rubber
• Insert: One high tensile steel wire braided insert
• Outer Layer: Synthetic rubber with high temperature, ozone and weather resistance
• Temperature Range: -40 to +100°C
• Media: Mineral oil, Polyglycol based oil, Water (0°C to + 70°C), Water-oil emulsions

2. 2SN/R2AT 2 – Wire Hydraulic Hose

• Application: For Medium high pressure circuits, return hoses
• Inner Layer: Oil resistant synthetic rubber
• Insert: Two high tensile steel wire braided insert
• Outer Layer: Synthetic rubber with high temperature, ozone and weather resistance
• Temperature Range: -40 to +100°C
• Media: Mineral oil, Polyglycol based oil ,Water (0°C to + 70°C) ,Water-oil emulsions

3. 1SN/R1AT 1 – Wire Super Service Hydraulic Hose

• Application: For low to medium high pressure lines requiring higher temperatures. High flexibility for use with minerals, glycols, polyglycols oils, synthetic ester oils, oils in water emulsion.
• Temperature Range: Continuous: -40°C to +155°C
• Core: Black colour, Synthetic rubber resistant to hot water
• Reinforcement: Single steel wire braid
• Cover: Synthetic rubber resistant to abrasion and weather, oil & ozone
• Feature: Great for pressure washer applications Suitable for higher temperatures

4. 2SN/ R2AT 2-Wire Super Service Hydraulic Hose

• Application: Medium high pressure lines requiring higher temperatures. High flexibility for use with minerals, glycols, polyglycols oils, synthetic ester oils, oils in water emulsion.
• Temperature Range: Continuous: -40°C to +155°C
• Core: Black colour, Synthetic rubber resistant to hot water
• Reinforcement: 2 high tensile steel wire braid
• Cover: Synthetic rubber resistant to abrasion and weather, oil & ozone.
• Feature: Great for pressure washer applications Suitable for higher temperatures.

5. 4-6 Wire High Pressure  Multi-Spiral Hydraulic Hose

• Application: Hydraulic Fluids and Lubricating Oils
• Inner Tube: Oil resistant synthetic rubber
• Reinforcement: 4-6 steel wire spirals
• Outer Cover: Oil & Weather resistant synthetic rubber
• Temperature Range: -40° - 120°

Get in touch with our sales team or access our full range of high pressure hydraulic hoses from www.boahub.co. We also supply hydraulic hoses in New Zealand and Australia.

In need of high pressure hose repair? We've got the right team for you. Let's get in touch.
